BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power

Large Image : BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power

Product Details:

Place of Origin:	Beijing
Brand Name:	Cansec Wireless
Model Number:	BLE52810SA-A

Payment & Shipping Terms:

Minimum Order Quantity:	100
Price:	USD 3.11$ per piece
Packaging Details:	Box for 1000 pieces Package size: 403420 cm Gross weight: 5.000 kg
Delivery Time:	3~6 weeks
Payment Terms:	T/T
Supply Ability:	2000000 pieces per year

Contact Now

BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power

Description

Size:	1522.82.8mm	TX Power:	3dBm
RX Sensitivity:	-96dBm	TX Current:	22mA
RX Current:	15mA	Standby Current:	1uA
Antenna Type:	PCB Antenna	Chipset:	Nrf52810 By Nordic
Data Rate:	2M
High Light:	NORDIC Bluetooth 5.0 Module , BLE52810SA-A , Ultra Low Power ble 5.0 module

Highly Flexible Ultra-Low Power Wireless Blue Tooth 5.0 Module IoT Cansec Ble52810SA-A Nordic NRF52810-QFAA

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.7	-	3.6	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	0.5	-	uA
	Receive mode	-	15	-	mA
	Transmit Mode	-	22	-	mA
TX Power (For Carrier)		-	3	-	dBm
RX Sensitivity (For Lora Modulation)		-	-	-96	dBm
Distance		160			m

Highly Flexible Ultra-Low Power Wireless Blue Tooth 5.0 Module IoT Cansec Ble52810SA-A Nordic NRF52810-QFAA

1. The BLE52810 module is based on nRF52810 SoC which is a powerful, highly flexible ultra-low power multiprotocol SoC ideally suited for Bluetooth® Low Energy, ANT and 2.4GHz ultra low-power wireless applications.

2. The nRF52810 SoC is built around a 32-bit ARM® Cortex™-M4F CPU with 192kB + 24kB RAM.

3. The embedded 2.4GHz transceiver supports Bluetooth Low Energy, ANT and proprietary 2.4 GHz protocol stack.

4. It is on air compatible with the nRF51 Series, nRF24L and nRF24AP Series products from Nordic Semiconductor.

Application:

IoT related

Wearable

Smart Home

Voice-command smart remotes

A4WP "Rezence" wireless charging

Beacons

Sport fitness sensors and hubs

Connected health products

BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power 1

BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power 4

BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power 5

BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power 6

BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power 7

BLE52810SA-A NORDIC Bluetooth 5.0 Module Highly Flexible Ultra Low Power 8

FAQ

Q1: Are you a factory or trade company?

A1: We are a professional factory with 25 years experience.

Q2: Can you accept OEM/ODM?

A2: Sure, we have rich OEM&ODM experience.

Q3: Do you have quality assurance?

A3; Each of our products has undergone quality testing and has two years of free after-sales service.
