100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810
100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810

Large Image :  100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810

Product Details:
Place of Origin: Beijing
Brand Name: Cansec Wireless
Model Number: BLE52810SA-A
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: USD 3.11$ per piece
Packaging Details: Box for 1000 pieces Package size: 40*34*20 cm Gross weight: 5.000 kg
Delivery Time: 3~6 weeks
Payment Terms: T/T
Supply Ability: 2000000 pieces per year

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810

Description
Size: 15*22.8*2.8mm TX Power: 3dBm
RX Sensitivity: -96dBm TX Current: 22mA
RX Current: 15mA Standby Current: 1uA
Antenna Type: PCB Board Antenna Chipset: Nordic Nrf52810
Max Range: 100M+ Protocol: Bluetooth Low Energy
High Light:

BLE 5.0 Low Energy Bluetooth Module

,

100M Low Energy Bluetooth Module

,

Nordic NRF52810 Module

Multiprotocol Soc Ble 5.0 Module Low Energy 2.4Ghz Cansec Ble52810SA-A Nordic NRF52810-QFAA Module IoT

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 0
Parameter
Min
Typ
Max
Unit
Operating Voltage
1.7
-
3.6
V
Operating Temperature
-20
-
+70
Current
Consumption
Sleep Mode
-
0.5
-
uA

Receive mode
-
15
-
mA

Transmit Mode
-
22
-
mA
TX Power (For Carrier)
-
3
-
dBm
RX Sensitivity (For Lora Modulation)
-
-
-96
dBm
Distance
160
m



Multiprotocol Soc Ble 5.0 Module Low Energy 2.4Ghz Cansec Ble52810SA-A Nordic NRF52810-QFAA Module IoT

1. The BLE52810 module is based on nRF52810 SoC which is a powerful, highly flexible ultra-low power multiprotocol SoC ideally suited for Bluetooth® Low Energy, ANT and 2.4GHz ultra low-power wireless applications.


2. The nRF52810 SoC is built around a 32-bit ARM® Cortex™-M4F CPU with 192kB + 24kB RAM.
3. The embedded 2.4GHz transceiver supports Bluetooth Low Energy, ANT and proprietary 2.4 GHz protocol stack.
4. It is on air compatible with the nRF51 Series, nRF24L and nRF24AP Series products from Nordic Semiconductor.

Application:
Internet of Things
Computer Perpherals
Smart watches
RC toys
Interactive games
Building automation and sensor network

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 1



100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 2
100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 3



100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 4

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 5

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 6

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 7

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 8

100M BLE 5.0 Low Energy Bluetooth Module Nordic NRF52810 9
FAQ
Q1: Are you a factory or trade company?
A1: We are a professional factory with 25 years experience.
Q2: Can you accept OEM/ODM?
A2: Sure, we have rich OEM&ODM experience.
Q3: Do you have quality assurance?
A3; Each of our products has undergone quality testing and has two years of free after-sales service.
