Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE
Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE

Large Image :  Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE

Product Details:
Place of Origin: Beijing
Brand Name: Cansec Wireless
Model Number: LRW32NA-C
Payment & Shipping Terms:
Minimum Order Quantity: 1000
Price: USD5.5$ Per Piece
Packaging Details: Three layers of protection anti-static bag & moisture-proof & cardboard box ensure transportation safety
Delivery Time: 5-8 weeks
Payment Terms: T/T
Supply Ability: 20000000 units per year

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE

Description
Chipset: ST-STM32WLE Size: 13*13*2.8mm
Operating Temperature: -20 - 70℃ Operating Voltage: 2.5-3.7V
TX Power: 20dBm RX Sensitivity: -140dBm
Sleep Current Consumption: 2μA Product Type: RF Module
Working Frequency: 433/470/868/915MHz Application: Industrial,Various Long Range Comminication,meter Reading
High Light:

Lorawan 433MHz Lora Module

,

433MHz Lora Gateway Module

,

ST-STM32WLE Lora Gateway Module

Small Size Cansec Lorawan Protocol LRW32NA-C Iot Lora Gateway Module Base ST-STM32WLE Lora Iot Output Module

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 0

Parameter
Min
Typ
Max
Unit
Operating Voltage
2.5
3.3
3.7
V
Operating Temperature
-20
-
70
°C
Current
Consumption
Rest
-
2

uA
Receive
-
12.5

mA
Transmit Mode
-
120

mA
TX Power
-

20
dBm
RX Sensitivity
-
-140

dBm



Feature

- LoRa spread spectrum modulation technology
- Receive sensitivity as low as -141dBm
- Excellent resistance to blocking
- Support preamble detection
- Support half-duplex SPI communication
- Programmable bit rate up to 300kbps
- Supports automatic RF signal detection, CAD mode and ultra high-speed AFC
- Packets with CRC, up to 256 bytes
- Small package with double volume stamps

Application
Smart meters
Supply chain and logistics
Building automation
Agricultural sensors
Smart cities
Retail store sensors
Asset tracking
Street lights
Parking sensors
Environmental sensors
Healthcare
Safety and security sensors
Remote control applications


Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 1

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 2

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 3
Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 4

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 5

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 6

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 7

Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 8


Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 9
Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 10
Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 11
Lorawan 433MHz Lora Module Lora Gateway Module Base ST-STM32WLE 12
FAQ
Q1: Are you a factory or trade company?
A1: We are a professional factory with 25 years experience.
Q2: Can you accept OEM/ODM?
A2: Sure, we have rich OEM&ODM experience.
Q3: Do you have quality assurance?
A3; Each of our products has undergone quality testing and has two years of free after-sales service.
